技術規格：

Input:

Input range：90Vac~264Vac

Frequency：47Hz~63Hz

Input current：1.0A Max at 100Vac input voltage

Efficiency：83% Min. at nominal input voltage, maximum load and measured at the end of DC cable

Output

Output Power：36W

Output Volts/Amps：12.0V/3.0A

Output ripple and noise：350 mV peak to peak

Dimensions (mm)

L85.0 x W36.0 x H26.3
